PON EDFA 32×19 dBm Dual optical output
Dual Input with Switch (Optional)
• Combined Output Connector SC I APC (Green)
• JDSU Pump
• Dual SMPS
• Adopts Er Yb Co doped double-clad fiber technology Combined Output connector SC I APC (Green)
• Extremely Low Noise Jdsu/ Equivalent Pump Lasers With Wide Optic Wavelength Range
• Catv Pass Through Wavelength is 1545-1565nm
• PON Pass Through Wavelength 1260-1360nm /1480-1500nm
• Catv Optic /p Range: -3 ~ +10dbm
• Isolators At Both I/p And O/p
•PON Insertion Loss < 0.8db
• Microprocessor Controlled Pump Laser
• Front Panel Display Of All Parameters
• Provision For Network Interface Through Rs232 / Lan
Description
Product Highlights
-
32 Output Ports @ 19 dBm Each
Uniform high-power distribution—ideal for large-scale fiber deployments. -
Dual Optical Outputs
Ensures redundancy or dual-path PON-CATV signal distribution for reliable service delivery. -
Integrated WDM Multiplexer
Built-in 1310 nm / 1490 nm / 1550 nm combiner per port—efficiently merges CATV & PON signals. -
Low Noise, High Stability
≤5 dB noise figure, ±1 dB flatness, and ±0.2 dBm power stability for crystal-clear signal quality. -
Dual Optical & Power Inputs
Supports automatic switchover between optical sources and dual AC/DC power supplies for uninterrupted operation. -
Remote Management via Web/SNMP
Convenient monitoring and configuration through RJ45 LAN port and LCD front panel.
